Acrylic Laser Cutting Machine price

Z3030 is a type of cnc router which is specalized to sign industry, school and enterprise and public institution, with smaller footprints and easy operation.

Technical Parameter cnc mini router:
Model Z3030
X,Y working area 300×300mm
Z Max working area ＞100mm
Table size 350x350mm
Working delicacy 0.05mm
X,Y,Z repositioning Positioning
accuracy  0.05mm
Frame Steel structure
X,Y, Z Structure Round orbit Ball screw (Y axis double nuts)
Max.Speed 4m~5.5m/min
Spindle Power Motor 1.5Kw water cooling spindle
Power (not include the spindle) 300w
Spindle Speed 0-24000RPM
Drive Motors  Stepper system
Working Voltage AC220V/50Hz
Command Language  G code
Operating System Computer control
Running Environment  Temperature: 0 ~ 45
Relative humidity: 30% ~ 75%
Surrounding for software Windows98/2000/xp
Packaging Plywood
Optional  DSP handle control system (with USB connection)
X,Y,Z axis change to Taiwan import Hiwin square orbit
Change Y axis to square orbit
Change to 2.2KW (220V)
Flume

Field of application:
Advertising industry, seal industry, craft and gift, art mould, wood working, mould etc. applicable material including on arylic, double-color board, PVC, ABS board, stone, imitation stone, metal, Aluminum Mold etc.

Samples of mini cnc machine and small cnc router:Acrylic Laser Cutting Machine price
